Sansui AU-888

Solid State Stereo Amplifier (1971-72)

Spesification

• Power output: 45 watts per channel into 8Ω
• Frequency response: 15Hz to 50kHz
• Total harmonic distortion: 0.4%
• Damping factor: 20
• Input sensitivity: 2mV (mic), 2mV (MM), 180mV (DIN), 180mV (line)
• Signal to noise ratio: 80dB (mic), 80dB (MM), 85dB (line)
• Channel separation: 50dB (MM), 50dB (line)
• Output: 180mV (line), 30mV (DIN)
• Speaker load impedance: 4Ω to 16Ω
• Semiconductors: 41 x transistor, 12 x diodes, 2 x SCR
• Dimensions: 460 x 140 x 305mm
• Weight: 12.6kg
